Specifications
Specifications| Network Interface | ● 8 RJ45 ports with 10/100Mbps PoE function (Port 1~Port 8) ● 2 10/100Mbps non-PoE function RJ45 ports (Port 9~Port 10) | ||
| Network Protocol Standard | ● IEEE 802.3i、 IEEE 802.3u、IEEE 802.3x、IEEE 802.3af、 IEEE 802.3at | ||
| Performance Specifications | ● Backplane Bandwidth: 2.0Gbps (non-blocking) ● Packet forwarding rate: 1.49Mpps ● MAC address table: 2K ● Forwarding Mode: Store and Forward | ||
| LED Indicator | ● Power Indicator ● LINK/ACT indicator ● PoE indicator ● RESV: reserved | ||
| PoE Pin | ● 1/2( +) ，3/6(-) | ||
| Power Support | ● Single port maximum output power: 30W ● The maximum power of the whole machine: 96W | ||
| Physical Specifications | ● Dimensions (LxWxH): 184mm*94mm*27mm | ||
| Environmenta Specifications | l | ● Operating temperature: 0°C~40°C ● Storage temperature: -40℃ ~ 70℃ ● Working humidity: 10%~90% RH non-condensing ● Storage humidity: 5%~90% RH non-condensing | |
| Safety Regulations | ● CE/ROHS/FCC/CCC | ||
